Orion-Tr 12/48-8A (380W) insulated

Orion-Tr 12/48-8A (380W) insulated

Orion-Tr 12/48-8A (380W) insulated

Orion-Tr DC-DC converter 12/48-8A (isolated) with a continuous output power of 380W. This DC-DC converter has an input voltage range of 10-17V and an adjustable output voltage of 40 to 60V. The continuous output current at a nominal output voltage of 48.2V and 40°C is 8A. The completely separate circuit ensures galvanic isolation between the two voltage sides, so that the input and output are completely isolated. All Orion-Tr models are short circuit resistant and can be connected in parallel to increase output power. Remote On-Off The remote on-off eliminates the need for a high-current switch in the input wiring. The remote on-off can be controlled with a low-power switch or, for example, by the on/off switch of the engine (see manual). IP43 protection When installed with the screw terminals facing downwards. Screw terminals No special tools required for installation. Input fuse (not replaceable) Only on 12V and 24V models. Adjustable output voltage Not intended for charging batteries. Consider using an Orion-Tr Smart for battery charging

We'd be happy to provide you with more information about this product. Please contact us.
