Victron AGM Battery 12V/90Ah

Victron AGM Battery 12V/90Ah

Victron AGM Battery 12V/90Ah Victron AGM Battery 12V/90Ah A commonly used size for service banks in motorhomes, boats, and tiny houses, and for backup power supplies for inverters up to approximately 1000 W. The flat copper terminals carry high currents without loose battery terminals or clamps. Flat-plate AGM for cyclic use The flat plates with fiberglass mat hold the electrolyte. The battery can be installed in any position except upside down and is designed for repeated deep discharge and recharge. Low internal resistance The low internal resistance makes the battery suitable for applications with high current draw, such as inverters, bow thrusters, and winches. This is where AGM distinguishes itself from gel. Flat copper terminals The flat copper terminals are provided with holes for M8 bolts. The large contact surface limits contact resistance; loose battery terminals or clamps are not required. Very low self-discharge Self-discharge remains below 2% per month at 20 °C. As a result, the battery remains usable for a long time even without intermediate charging, for example during winter storage. Charging The recommended absorption voltage is 14.6 to 14.9 V and the trickle charge voltage is 13.5 to 13.8 V. The maximum charging current is 0.2 C, or 18 A for this battery. Sealed and maintenance-free The VRLA construction is completely sealed. Adding water is not possible and not necessary. The battery is delivered charged and is ready for immediate use. The housing is made of fire-retardant ABS. Related products * Victron AGM Battery 12V/90Ah M6 insert (https://shop.top.systems/accu-s/agm/victron-agm-accu-12v-90ah-m6-insert.html) — BAT412800085 * Victron AGM battery 12V/110Ah (https://shop.top.systems/accu-s/agm/victron-agm-accu-12v-110ah.html) — BAT412101084 * Victron AGM Battery 12V/130Ah (https://shop.top.systems/accu-s/agm/victron-agm-accu-12v-130ah.html) — BAT412121084 Documentation * Datasheet Gel and AGM batteries (NL) (https://www.victronenergy.com/upload/documents/Datasheet-GEL-and-AGM-Batteries-NL.pdf) * Datasheet Gel and AGM Batteries (EN) (https://www.victronenergy.com/upload/documents/Datasheet-GEL-and-AGM-Batteries-EN.pdf) * Dimensions AGM Deep Cycle 12V 90Ah (EN) (https://www.victronenergy.com/upload/documents/Dimension-Drawing-BAT412800084-12V90Ah-AGM-Deep-Cycle-Batt.pdf) * Material Declaration 12V 90Ah AGM Deep Cycle (EN) (https://www.victronenergy.com/upload/documents/MD-12V-90Ah-AGM-Deep-Cycle-Batt..pdf) * Declaration of Conformity for Lead-Acid and Carbon Batteries (EN) (https://www.victronenergy.com/upload/documents/Declaration-of-Conformity-Lead-Acid-and-Carbon-Battery281125.pdf) * VRLA Battery Safety Data Sheet (EN) (https://www.victronenergy.com/upload/documents/Material-Safety-Data-Sheet-VRLA-Battery-EN.pdf) * Battery Regulation Information (EN) (https://www.victronenergy.com/upload/documents/Battery-Regulation-EN.pdf) * ISO 9001 Certificate (EN) (https://www.victronenergy.com/upload/documents/ISO9001-certificate-2024-EN.pdf) Videos * Did You Know – How to look after your lead-acid battery (Victron Energy) (https://youtu.be/f2Rnn0-pkCw) * Did You Know – why Is there a C value or 20h indication on a battery? (Victron Energy) (https://youtu.be/FTF_WDfNr8g) * How to set up BMV Battery Monitor for lead and lithium batteries (Victron Energy) (https://www.youtube.com/watch?v=mEN15Z_S4kE) Contact Would you like to know how many of these batteries your installation requires, or which charger is suitable? Our specialists would be happy to calculate your battery bank requirements with you. Please contact us (https://www.top.systems/nl/contact/). Specifications Nominal voltage 12 V Nominal capacity (20 hours, 25 °C) 90 Ah Technology Flat-plate AGM, VRLA Connections Flat copper terminal with bore for M8 bolt Absorption voltage 14.6 – 14.9 V Trickle charge voltage 13.5 – 13.8 V Storage voltage 13.2 – 13.5 V Max. Charging current 0.2 C (18 A) End-discharge voltage (20 hours) 10.8 V Self-discharge Less than 2% per month at 20 °C Lifecycle 400 cycles at 80% DoD, 600 at 50% DoD, 1500 at 30% DoD Housing Flame-retardant ABS Dimensions (LxWxH) 350 x 167 x 183 mm Weight 27 kg Warranty 2 years EAN 8719076037170 We would be happy to provide you with more information about this product. Please contact us contact join us.
