Victron Phoenix Smart IP43 Battery Charger 24/25 (1+1) 120-240V A 24 V shore power charger of 25 A for workboats, yachts, and vehicles where the starter battery needs to be recharged in addition to the service bank. Bluetooth is built-in, so setup and data retrieval are done via smartphone: no panel, no extra cabling. Main output plus starter battery output The main output delivers the full 25 A to the service bank. Additionally, there is a second output of up to 4 A that keeps the starter battery charged. This allows you to charge both battery banks from a single charger, without an extra isolation diode or charge current distributor. Six-stage adaptive charging algorithm By default, the charger charges according to a 6-stage adaptive algorithm with absorption at 28.8 V, float at 27.6 V, and storage at 26.4 V. In high mode, the absorption voltage goes to 29.4 V, and in lithium mode to 28.4 V using a 3-stage algorithm. The temperature compensation is -32 mV/°C. Bluetooth and VictronConnect Bluetooth is built-in. With the VictronConnect app on your smartphone, you set the battery type, charging current, and alarms, and read the charging status and history. Firmware updates are handled via the same app. Low current mode for small battery banks With low current mode, you halve the charging current to 12.5 A. This is intended for situations where the full current is too much for the connected battery or for the available shore connection. VE.Direct and remote on/off Via the VE.Direct port, you connect the charger to a GX device or directly to VictronConnect. The two-pole remote on/off input enables switching from a panel or from a lithium battery management system. Input and housing Input voltage 85 – 250 Vac (full power from 100 Vac, startup from 90 Vac) at 45 to 65 Hz. The housing is made of aluminium in RAL 5012, with IP43 for the electronics and IP22 for the connection area. Operating temperature -20 to 60 °C at a maximum of 95% relative humidity, non-condensing. Protected against reverse battery polarity (internal fuse), output short circuit, and overtemperature. Order power cord separately. The charger is supplied without a power cord. Order the CEE 7/7 power cord (ADA010100100 (https://shop.top.systems/default.asp?pageid=88&webgroupfilter=17&artdetail=ADA010100100)) separately. Can be ordered directly with this item * Red battery cable 10mm² per meter (https://shop.top.systems/default.asp?pageid=88&webgroupfilter=17&artdetail=KABRD0101000) – KABRD0101000 * Black battery cable 10mm² per meter (https://shop.top.systems/default.asp?pageid=88&webgroupfilter=17&artdetail=KABZW0101000) – KABZW0101000 * Cable set 10mm² 1.5 m red and black M8 (https://shop.top.systems/default.asp?pageid=88&webgroupfilter=17&artdetail=KABSET010100) – KABSET010100 * Red battery cable 10mm² 150cm 1 x M8 (https://shop.top.systems/installatie/kabels/accu/accukabel-rood-10mm-150cm-1-x-m8.html) – KABRD101508M, found in the category Battery cables (https://shop.top.systems/installatie/kabels/accu/) * Battery cable Black 10mm² 150cm 1 x M8 (https://shop.top.systems/installatie/kabels/accu/accukabel-zwart-10mm-150cm-1-x-m8.html) – KABZW101508M, found in the category Battery cables (https://shop.top.systems/installatie/kabels/accu/) * Crimp cable lug 10mm² > M6 (https://shop.top.systems/installatie/accessoires-kabels/perskabelogen/perskabeloog-10mm-m6.html) – PSKABOG00010, found in the category Press cable eyes (https://shop.top.systems/installation/accessories-cables/press-cable-eyes/) * Press-cable eye 10mm² > M8 (https://shop.top.systems/installation/accessories-cables/press-cable-eyes/pers-cable-eye-10mm-m8.html) – PSKABOG00011, can be found in the category Press-cable eyes (https://shop.top.systems/installation/accessories-cables/press-cable-eyes/) * Press-cable eye 10mm² > M10 (https://shop.top.systems/installation/accessories-cables/press-cable-eyes/pers-cable-eye-10mm-m10.html) – PSKABOG00012, can be found in the category Press-cable eyes (https://shop.top.systems/installation/accessories-cables/press-cable-eyes/) * Press cable eye 10mm² > M12 (https://shop.top.systems/installatie/accessoires-kabels/perskabelogen/perskabeloog-10mm-m12.html) – PSKABOG00013, found in the category Crimp lugs (https://shop.top.systems/installatie/accessoires-kabels/perskabelogen/) * Power cord CEE 7/7 smart IP43/Skylla 2m (https://shop.top.systems/default.asp?pageid=88&webgroupfilter=17&artdetail=ADA010100100) – ADA010100100 Related products * Victron Phoenix Smart IP43 battery charger 24/25 (3) 120-240V (https://shop.top.systems/omvormen-laden/acculaders/victron-phoenix-smart-ip43-acculader-24-25-3-120-240v.html) – PSC242553095 * Victron Phoenix Smart IP43 battery charger 24/16 (1+1) 120-240V (https://shop.top.systems/omvormen-laden/acculaders/victron-phoenix-smart-ip43-acculader-24-16-1-1-120-240v.html) – PSC241651095 Documentation * Smart IP43 Charger 120-240V Manual (English) (https://www.victronenergy.com/upload/documents/Smart_IP43_Charger_120-240V/109244-Smart_IP43_Charger_120-240V-pdf-en.pdf) * Smart IP43 Charger 120-240V Datasheet (English) (https://www.victronenergy.com/upload/documents/Datasheet-Smart-IP43-Charger-120-240V-EN-.pdf) * Dimensioning drawing Smart IP43 Charger (1+1) 120-240V (https://www.victronenergy.com/upload/documents/Smart-IP43-charger-(1+1)-120-240V.pdf) * Declaration of Conformity Smart IP43 Chargers (EU DoC RED) (https://www.victronenergy.com/upload/documents/Smart-IP43-Chargers-EU-DOC-RED.pdf) * Safety Certificate EN/IEC 60335-1 and -2 (English) (https://www.victronenergy.com/upload/documents/Certificate-Safety-EN-IEC-60335-1-2-Smart-IP43-Charger-120-240V.pdf) * Certificate AS/NZS 60335 (English) (https://www.victronenergy.com/upload/documents/Certificate-AZ-NZS-60335-Smart-IP43-Charger.pdf) Contact Are you unsure whether to choose the version with a starter battery output or the one with three outputs, or about the cable cross-section for this charging current? Our technical advisors are happy to help. Please contact us (https://www.top.systems/nl/contact/). Specifications Battery voltage 24 V Charging current 25 A Low current mode 12.5 A Outputs Two (main output plus starter battery output) Charging current starter battery output Max. 4 A Absorption voltage 28.8 V (normal), 29.4 V (high), 28.4 V (lithium) Float voltage 27.6 V Storage voltage 26.4 V Temperature compensation -32 mV/°C Charging characteristic 6-stage adaptive, 3-stage for lithium Input voltage 85 – 250 Vac (full power from 100 Vac, startup from 90 Vac) Input frequency 45 – 65 Hz Power factor 1 Efficiency 96 % No-load consumption 1 W Back current < 1 mA Bluetooth Built-in VE.Direct Yes Remote on/off Yes, two-pole connection Protections Reverse battery polarity (internal fuse), output short circuit, over temperature Operating temperature -20 to 60 °C Relative humidity Max. 95%, non-condensing Housing Aluminium, RAL 5012 Protection class IP43 electronics, IP22 connection area Dimensions (hxwxd) 180 x 249 x 116 mm Weight 2.7 kg Safety EN 60335-1, EN 60335-2-29 EMCEN 55014-1, EN 61000-6-3, EN 61000-3-2 Vibration IEC 68-2-6, 10-150 Hz / 1.0 G We would be happy to provide you with more information about this product. Please contact us contact join us.
